QTJ4-25

1) It adopts PLC intellectual control and stepping operation. The whole process is automatically completed from automatically feeding

Product Description
production capacity400x200x200mm   4840 pieces /8hour    400x150x200mm   5800 pieces/8hour     400x100x200mm   7720 pieces/8hour
power21 kw
overall size3000X1950X2400mm
cycle25 seconds
pallets size850x470x30mm
vibration force450KN
vibration frequency4000-4800/Minute
rated pressure14Mpa
total weight5000kg
electricity source380v/50HZ


1) It adopts PLC intellectual control and stepping operation. The whole process is automatically completed from automatically feeding, automatically flattening mould to automatically carrying finished product. There is interlocking or mutual locking function in related procedures for automatic protection and high reliability

2) It achieves powerful vertical directional table model vibration by lower power. The skilful feeding distribution device can provide shape building blocks with dense uniform complete surface and high strength

3) A machine has several purposes. The machine can produce trig, multi-hole brick and air building block if using different dies

4) The machine body and key components are made of cast steel to be tight, durable and artistic. The consumer can make production through continuous several shifts.
